| Features | ||
| ● Osram LEDs, high lumen output over 140lm/W. ● 360° annular LED light source distribution, anti-glare. ● Extruded copper-free aluminum, high intensity, can endure 20J impact. ● Capable to work at extreme high and low temperature -45℃～+60℃, keep good performance. ● IP66 and high corrosion resistance, can be used in ocean environment. ● Lightning protection 6KV, THD≤ 5%. ● Various installation methods. |
||
| Applications | ||
| ● Ex d IIC 101℃(T4) Gb. For Zone 1 & Zone 2, Class l Division 1 & Class l Division 2. Ex tb IIIC T96℃ Db IP66. For Zone 21 & Zone 22, CIass II Division 1 & Class II Division 2. Especially can be used in hydrogen exsiting enviorment. ●Ideal for oil and gas industry, refineries, onshore and offshore rigs, pumping station, oil tank, petrochemical plants, mining, power generation, wharf and loading docks, etc. |
||
| Technical Parameters | ||
| Model No. | 100W | 110W |
| Power Consumption | Ex-BLP100 | Ex-BLP110 |
| Input Voltage & Frequency | AC 100-277V 47-62Hz |
|
| Input Current | 100～330mA | 260～880mA |
| Power Factor (PF) | ≥0.98 | ≥0.98 |
| LED Chips Brand |
OSRAM or Other efficient | |
| Luminous Flux | 12000lm | 13200lm |
| Dimensions | φ258*86mm | |
| Weight | 3.8kg | |
| Color Rendering Index (CRI) | Ra > 70 | |
| Color Temperature | WW: 2800～3300K PW: 4700～5400K CW:5700～7100K |
|
| Beam Angle |
40°/80°/120° | |
| Working Ambient Temp. | -45℃～+60℃ | |
| IP Grade |
IP66 | |
| Lifespan | ≥50000hrs | |
| Housing Material | Copper-free aluminum | |
| Front Cover Material | Tempered glass | |
